Part 1 – QBlade Wind Turbine Simulation Software with GUI

Introduction

In past posts, an opensource programme for simulation of wind turbines and a limited wind farm configuration was covered. It is called OpenFAST. A nice programme it is; however, it does not have an interactive user interface. Introduced here is QBlade which has similar models of wind turbines as OpenFAST as a free programme plus, it has a graphical user interface. The video below shows further some functionalities of QBlade.

See also:

  1. Onshore Structural Design
  2. How to Design Each Facility Feature
  3. Horizontal Vessel Design
  4. Vertical Vessel Design
  5. Above Ground Storage Tank Design
  6. Design Overview of a Wind Farm
  7. Wind Turbine System Design
  8. BladeComp Structural Blade Modelling
  9. PyWake Wind Farm Simulation Programme

A simplified collection of calculations for onshore structures can be obtained from here: https://www.amazon.com/ONSHORE-STRUCTURAL-DESIGN-STEP-CALCULATIONS/dp/B08Z3QPNP5

Also available in Nigeria for: ₦18,500.00 Contact – +2348182035528

Udemy course: Onshore Structural Design – Step by Step Calculations | Udemy

User Documentation

With the understanding that wind turbine design is a broad subject, attached here is a user documentation.

Opportunities to explore the application can be found here: https://docs.qblade.org/

Also downloadable here:

QBlade User DocumentationDownload
